tp-link VIGI C540V 4MP (4MM - 12MM) Outdoor Full-Color Dual-Lens Varifocal Pan Tilt Network Camera

tp-link VIGI C540V 4MP (4MM - 12MM) Outdoor Full-Color Dual-Lens Varifocal Pan Tilt Network Camera

CAMERA :

• Image Sensor : 1/3” Progressive Scan CMOS

• Shutter Speed : 1/3 to 1/10000 s

• Slow Shutter : Yes

• Minimum Illumination :

  • 0.005 Lux; 0 Lux with IR/white light

• Day/Night Mechanism : IR Cut Filter

• Day/Night Switch : Unified/ Scheduled/ Auto

• Zoom : 3x Mixed Zoom

LENS :

• Focal Length : 4-12 mm (Mixed Zoom)

• Aperture : F1.6

• FOV : Diagonal : 100°, Horizontal : 84°, Vertical : 46°

• Lens Mount : M12*P 0.5

• DORI (Detect, Observe, Recognize, Identify) Distance :

  • 4 mm :

    • 80 m (262 ft) x 33 m (109 ft) x 16 m (52 ft) x 8 m (26 ft)

  • 8 mm :

    • 150 m (493 ft) x 63 m (205 ft) x 30 m (98 ft) x 15 m (49 ft)

PTZ :

• Pan/tilt Range :

  • Pan: 0° to 332°

  • Tilt: 0° to 120°

• Pan/tilt Speed :

  • Pan Speed :

    • Configurable from 8° to 44°/s; Preset Speed: 44°/s

  •  Tilt Speed :

    • Configurable from 8° to 44°/s, Preset Speed 44°/s

• Manual Control Speed : Configurable from 8° to 35°/s

• Presets : 300

• Patrol Scan : 8 patrols, up to 8 presets for each patrol

• Power-off Memory : Yes;

  • Auto restore to previous PTZ and lens status after power failure

• Park Action : Yes;

  • Preset; Patrol Scan

• 3D Positioning : Yes

• Angle Adjustment (Manual) Range :

  • Pan: 0° to 332°

  • Tilt: 0° to 120°

ILLUMINATOR :

• IR LED :

  • Quantity : 1

  • Range : 30m

  • Wavelength : 850nm

• White LED :

  • Quantity : 3

  • Range : 30m

• Illuminator On/Off Control :

  • Auto/Scheduled/Always on/Always off

VIDEO :

• Max. Resolution : 2560 X 1440

• Main Stream :

  • Frame Rate：

    • 50Hz : 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

    • 60Hz : 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  •  Resolution :

    • 2560x1440

    • 2304x1296

    • 2048x1280

    • 1920x1080

    • 1280x720

• Sub-Stream :

  • Frame Rate：

    • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

    • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  •  Resolution :

    • 640x480, 352x288, 320x240

• Bit Rate Control CBR, VBR

• Video Compression :

  • Main Stream : H.265+/H.265/H.264+/H.264

  • Sub-Stream : H.265/H.264

• H.264 Type : High Profile

• H.264+ : Main Stream Supported

• H.265 Type : Main Profile

• H.265+ : Main Stream Supported

• Video Bit Rate :

  • Main Stream : 256 Kbps to 4 Mbps

  • Sub-Stream : 64 Kbps to 512 Kbps

Image :

• Image Settings :

  • Mirror

  • Brightness

  • Contrast

  • Saturation

  • Sharpness

  • Exposure

  • WDR

  • White Balance

  • Prevent Overexposure to Infrared Light

  • HLC Adjustable by Client Software

• Image Enhancement : BLC/3D DNR/HLC/SmartIR

• Wide Dynamic Range : DWDR

• SNR : ≥ 52 dB

• Image Parameters Switch : Yes

• Privacy Mask : Up to 4 Masks

• ROI : 1 Region

• OSD Setting : Yes

AUDIO :

• Audio Communication : Two-Way Audio

• Audio Input : Yes

• Audio Output : Yes

• Audio Compression : Yes

• Audio Sampling Rate : 8KHz

• Environment Noise Filtering : Yes

• Audio Bit Rate : 64 Kbps(G.711 alaw)

NETWORK :

• Protocol :

  • TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP,

  • DNS, RTSP, NTP, UPnP UDP, SSL/TLS,

  • FTP/SFTP, RTP, IPv4, IPv6, ARP

• ONVIF : Yes

• API : Open Network Video Interface (Profile S)

• Simultaneous Live View : 3 Main Streams & 3 Sub-Streams

• Client : VIGI App, VIGI Security Manager, Web UI

• Web Browser :

  • Google Chrome® 57 and above

  • Firefox® 52 and above

  • Safari® 11 and above

  • Microsoft® Edge 91 and above

• Cloud : Yes

• Security :

  • Password Protection

  • HTTPS Encryption

  • IP Address Filter

  • Digest Authentication

ALARM AND EVENT MANAGEMENT :

• Smart Event :

  • Area Intrusion Detection

  • Line-Crossing Detection

  • People Detection

  • Vehicle Detection

  • Region Entering Detection

  • Region Exiting Detection

  • Object Abandoned Detection

  • Object Removal Detection

  • Abnormal Sound Detection

• Basic Event :

  • Motion Detection

    • (Enhanced with Human & Vehicle Classification for more accurate alerts)

  • Video Tampering Detection

  • Exception ( Illegal Login)

• Alarm Linkage :

  • Memory Card Video Recording

  • Message Push

  • Audible Warning

  • White Light Flashing

INTERFACES :

• Network Interface : 1

  • RJ45 10/100M Self-Adaptive Ethernet Port, PoE

• Alarm : N/A

• Reset Button : Yes

• Power : DC Power Port

• On-board Storage :

  • Built-In Memory Card Slot

  • Support MicroSD Card, up to 512 GB

• Built-in Microphone : Yes

  • Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera

• Built-in Speaker : Yes

• Audio : N/A

GENERAL :

• Operating Temperature : -30–60 °C

• Storage Temperature : -40–60 °C

• Operating Humidity : 95% or Less (Non-Condensing)

• Storage Humidity : 95% or Less (Non-Condensing)

• Material : Plastic

• Net Weight : 0.43 Kg

• Gross Weight : 0.66 Kg

• Power Supply :

  • 12V DC ± 5%, Max. 14 W, 5.5mm Coaxial Power Plug

  • PoE : 802.3at, class 4, Max. 16 W

• Protection : IP66

• Product Dimensions (L x W x H) : 107× 136× 139 mm

In the Box :

• VIGI Network Camera

• Quick Start Guide

• Waterproof Cable Attachments

• Mounting Accessories

Certifications : CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
