tp-link VIGI C440-W 4MP (4MM) Full-Color Wi-Fi Turret Network Camera

tp-link VIGI C440-W 4MP (4MM) Full-Color Wi-Fi Turret Network Camera

CAMERA :

• Image Sensor : 1/3” Progressive Scan CMOS

• Shutter Speed : 1/3 to 1/10000 s

• Slow Shutter : Yes

• Minimum Illumination : 0.005 Lux; 0 Lux with IR/White Light

• Day/Night Mechanism : IR Cut Filter

• Day/Night Switch : Unified/ Scheduled/ Auto

LENS :

• Type : Fixed Focal Lens

• Focal Length : 4 mm

• Aperture : F1.6

• FOV : Horizontal : 80°, Vertical : 43.2°, Diagonal : 94.2°

• Lens Mount : M12

• DORI (Detect, Observe, Recognize, Identify) Distance :

  • 80 m (262 ft) x 33 m (109 ft) x 16 m (52 ft) x 8 m (26 ft)

• Angle Adjustment (Manual) Range :

  • Pan: 0° to 360°

  • Tilt: 0° to 85°

  • Rotate: 0° to 360°

ILLUMINATOR :

• IR LED :

  • Quantity: 2

  • Range: 30m

  • Wavelength: 850nm

• White LED :

  • Quantity: 2

  • Range: 30m

• Illuminator On/Off Control :

  • Auto/Scheduled/Always on/Always off

VIDEO :

• Max. Resolution : 2560 X 1440

• Main Stream :

  • Frame Rate :

    • 50Hz : 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

    • 60Hz : 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  •  Resolution :

    • 2560x1440

    • 2304x1296

    • 2048x1280

    • 1920x1080

    • 1280x720

  •  Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

• Sub-Stream :

  • Frame Rate:

    • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

    • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  • Resolution:

    • 640x480, 352x288, 320x240

  •  Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

• Bit Rate Control : CBR, VBR

• Video Compression :

  • Main Stream : H.265+/H.265/H.264+/H.264

  • Sub-Stream : H.265/H.264

• H.264 Type : Main Profile/High Profile

• H.264+ : Main Stream Supported

• H.265 Type : Main Profile

• H.265+ : Main Stream Supported

• Video Bit Rate

  • Main Stream : 256 Kbps to 3 Mbps

  • Sub-Stream : 64 Kbps to 512 Kbps

Image :

Image Settings :

• Mirror

• Brightness

• Contrast

• Saturation

• Sharpness

• Exposure

• WDR

• White Balance

• Prevent Overexposure to Infrared Light

• HLC Adjustable by Client Software

• Rotation (90°/270°)

• Image Enhancement : BLC/3D DNR/HLC/SmartIR

• Wide Dynamic Range : DWDR

• SNR : ≥ 52 dB

• Image Parameters Switch : Yes

• Privacy Mask : Up to 4 Masks

• ROI : 1 Region

• OSD Setting : Yes

AUDIO :

• Audio Communication : Two-Way Audio

• Audio Input : Yes

• Audio Output : Yes

• Audio Compression : Yes

• Audio Sampling Rate : 8KHz

• Environment Noise Filtering : Yes

• Audio Bit Rate : 64 Kbps (G.711 alaw)

NETWORK

• Protocol :

  • TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS,

  • RTSP, NTP, UPnP UDP, SSL/TLS

• ONVIF : Yes

• API : ONVIF

• Simultaneous Live View : 3 Main Streams & 3 Sub-Streams

• Client : VIGI App, VIGI Security Manager, Web UI

• Web Browser :

  • Google Chrome® 57 and above

  • Firefox® 52 and above

  • Safari® 11 and above

  • Microsoft® Edge 91 and above

• Cloud : Yes

• Security :

  • Password Protection

  • HTTPS Encryption

  • IP Address Filter

  • Digest Authentication

WIRELESS :

• WiFi Channels : 1-13

• Frequency : 2.4 GHz

• Wireless Transmit Power : High

• Auto Wireless Channel : N/A

• Wireless Statistics : N/A

• Throughput Monitoring : N/A

• Radio Bandwidth :

  • Auto : N/A

  • 20M : Yes

  • 40M : Yes

• Wireless Rate :

  • 11Mbps(802.11b)

  • 54Mbps(802.11g)

  • 150/300Mbps(802.11n)

• Wireless Security : PWPA/WPA2-PSK

• Wireless Mode : AP, AP Client

ALARM AND EVENT MANAGEMENT :

• Smart Event :

  • Human & Vehicle Classification

  • Area Intrusion Detection

  • Line-Crossing Detection

  • People Detection

  • Vehicle Detection

  • Region Entering Detection

  • Region Exiting Detection

  • Object Abandoned Detection

  • Object Removal Detection

• Basic Event :

  • Motion Detection

  • Video Tampering Detection

  • Exception ( Illegal Login)

• Alarm Linkage :

  • Memory Card Video Recording

  • Message Push

  • Audible Warning

  • White Light Flashing

• Linkage Method : N/A

• Output Notification : Message Push

INTERFACES :

• Network Interface : 1

  • RJ45 10/100M Self-Adaptive Ethernet Port

• Alarm : N/A

• Reset Button : Yes

• Power : DC Power Port

• On-board Storage :

  • Built-In Memory Card Slot

  • Support MicroSD Card, Up to 256 GB

• Built-in Microphone : Yes

  • Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera

• Built-in Speaker Yes

• Audio    N/A

GENERAL :

• Operating Temperature : -30–60 °C

• Storage Temperature : -40–60 °C

• Operating Humidity : 95% or Less (Non-Condensing)

• Storage Humidity : 95% or Less (Non-Condensing)

• Material : Plastic

• Net Weight : 0.24 Kg

• Gross Weight : 0.53 Kg

• Power Supply : 9V DC/0.85A, 5.5mm Coaxial Power Plug

• Antenna

  • Quantity : 2

  • Type : 2.4GHz Welded Dipole Omni-Directional Antenna

  • Gain : 2.0dBi

  • Protection : N/A

• Product Dimensions (L x W x H)  123× 83× 123 mm

In the Box :

• VIGI Network Camera

• Quick Start Guide

• Power Adapter

• Mounting Accessories

Certifications :

• CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, R-NZ
