EZVIZ Panoramic Fisheye 360° 6MP (3K+) for Indoor

EZVIZ Panoramic Fisheye 360° 6MP (3K+) for Indoor

• Model : CS-E4p-R100-8C6WKF

Compression :

• Image Sensor : 1/2.8” Progressive Scan CMOS

• Shutter Speed : Self-adaptive shutter

• Lens : M12

• Day & Night : IR-cut filter with auto switch

• DNR : 3D DNR

• WDR : Digital WDR

Compression :

• Image Sensor : 1/2.8” Progressive Scan CMOS

• Shutter Speed : Self-adaptive shutter

Image :

• Max. Resolution : 3K⁺ (2320 × 2320)

• Frame Rate : Max. 25 fps

Network :

• Smart Alarm :

  • Motion Detection

  • AI-Powered Human Shape Detection

• Wi-Fi Pairing : AP pairing

• Protocol : EZVIZ Cloud Proprietary Protocol

Interface :

• Storage : Supports microSD card (max. 512 GB)

• Power : Type-C

Wi-Fi :

• Standard :

  • IEEE802.11a, 802.11b, 802.11g, 802.11n, 802.11ac

• Frequency Range :

  • 2.4G: 2.412 GHz ~ 2.472 GHz

  • 5G: 5.17 GHz ~ 5.25 GHz

• Channel Bandwidth : Support 20 MHz

• Security : WPA / WPA2, WPA-PSK / WPA2-PSK

• Transmission Rate :

  • 11b 11 Mbps

  • 11g 54 Mbps

  • 11nHT20 MCS7

  • 11a 54 Mbps

  • 11nHT20 MCS7

  • 11ac MSC7

• Output Power (EIRP) : 19 dBm

• Antenna Gain : 2.4G: 1.79 dBi, 5G: 3.61dBi

General :

• Operating Conditions :

  • -10°C to 45°C (14°F to 113 °F ),

  • Humidity 95% or less (non-condensing)

• Power Supply : DC 5 V / 2 A

• Power Consumption : Max. 8 W

• IR Range : Max. 10 meters (32.81 ft)

• Product Dimensions :

  • φ80 × 35 mm (φ3.15 × 1.38 inch)

• Packaging Dimensions :

  • 114 × 114 × 120 mm (4.49 × 4.49 × 4.72 inch)

• Bare Weight : 122 g (4.3 oz)

• Weight : 610 g (21.52 oz)

In the Box :

• E4p Camera

• Mounting Base

• Drill Template

• Power Adapter

• Type-C Cable

• Screw Kit

• Pin Key

• Regulatory Information × 2

• Quick Start Guide

Certifications : CE / RoHS / REACH / WEEE / UL
