EZVIZ IP Camera PTZ Outdoor H80X Dual 8MP (4K) + 2MP (1080P)

EZVIZ IP Camera PTZ Outdoor H80X Dual 8MP (4K) + 2MP (1080P)

• Model : CS-H80x-R100-8G82WKFL

Camera :

• Image Sensor : 1/2.7” + 1/2.9” Progressive Scan CMOS

• Shutter Speed : Self-adaptive shutter

• Lens :

  • 4mm @ F1.0,

    Viewing angle :

    • 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (1080p)

  • 4mm @ F1.6,

    Viewing angle:

    • 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (4K)

• PT Angle Pan : 340°, Tilt: 70°

• Minimum Illumination :

  • 0.01 Lux @ (F1.0, AGC ON), 0 Lux with IR

    • (*data is obtained from EZVIZ laboratories)

• Lens Mount : M12

• Day / Night Switch : IR-cut filter with auto switch

• DNR : 3D DNR

• WDR : Digital WDR

• BLC : Supports

• Black & White Night : 30m / 98ft

Video & Audio :

• Max Resolution : 3840 × 2160

• Frame Rate : Self-Adaptive during network transmission

• Video Compression : H.265 / H.264

• H.265 Type : Main Profile

• Video Bit Rate :

  • Ultra HD; Quad HD; Full HD;HD. Adaptive bit rate.

• Audio Bit Rate : Self-Adaptive

Network :

• Wi-Fi Standard : IEEE802.11b, 802.11g, 802.11n

• Frequency Range : 2.4 GHz ~ 2.4835 GHz

• Channel Bandwidth : Supports 20MHz

• Security :

  • 64 / 128 - bit WEP

  • WPA / WPA2

  • WPA-PSK / WPA2 - PSK

• Transmission Rate :

  • 11b : 11 Mbps, 11g : 54 Mbps, 11n : 150 Mbps

• Wi-Fi Pairing : AP paring

• Protocol : EZVIZ Cloud Proprietary Protocol

• Interface Protocol : EZVIZ Cloud Proprietary Protocol

• Wired Network :

  • RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Functions :

• Smart Alarm :

  • AI-powered human shape detection

  • AI-powered vehicle shape detection

• Customized Alert Area : Supports

• Two-way Talk : Supports

• Auto Tracking : Supports

• General Function :

  • Anti-Flicker

  • Dual-Stream

  • Heart Beat

  • Password Protection

  • Watermark

Storage :

• Local Storage : Supports microSD Card (Up to 512 GB)

• Cloud Storage : Supports EZVIZ CloudPlay storage

  • (Subscription required)

General :

• Operating Conditions :

  • -30ºC ~ 50ºC

  • Humidity 95% or less (non-condensing)

• IP Grade : IP65

• Power Supply : DC 12V/1A

• Power Consumption : MAX. 12W

• Dimensions :

  • 170 × 112 × 154 mm (6.69 × 4.41 × 6.06 inch)

• Packaging Dimensions :

  • 205 × 176 × 194 mm (8.07 × 6.93 × 7.64 inch)

Weight :

• Product : 630 g (22.22 oz)

• Weight with package : 1035 g (36.5 oz)

In the Box :

• H80x Dual 4K Camera

• Drill Template

• Waterproof Kit

• Screw Kit

• Power Adapter

• Regulatory Information × 2

• Quick Start Guide

Certifications : CE / UL / WEEE / RoHS / REACH
