EZVIZ IP Camera Static Outdoor H3 5MP (3K)

EZVIZ IP Camera Static Outdoor H3 5MP (3K)

• Model : CS-H3c-R100-1J5WKFL

Camera

• Image Sensor : 1/2.7”Progressive Scan CMOS

• Minimum Illumination : 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR

• IR Night Vision Distance : Up to 98 ft / 30 m

• Shutter Speed : Self-adaptive shutter

• Lens :

  • 4mm @ F1.6, Viewing angle :

    • 87° (Horizontal), 53° (Vertical), 104° (Diagonal)

  • 2.8mm @ F1.6, viewing angle :

    • 103° (Horizontal), 58° (Vertical), 125° (Diagonal)

• Lens Mount : M12

• DNR : 3D DNR

• WDR : Digital WDR

• Day / Night Switch : IR-Cut filter with auto-switching

Video & Audio :

• Max. Resolution : 2880*1620

• Frame Rate : Max: 30fps;

  • Self-Adaptive during network transmission

• Video Compression : H.265 / H.264

• Video Bit Rate : Quad HD; Hi-Def; Full HD; Standard.

• Audio Bit Rate : Self-Adaptive

• Max. Bitrate : 2.5 Mbps

Network :

• Wi-Fi Standard : IEEE802.11b, 802.11g, 802.11n

• Frequency Range : 2.4 GHz ~ 2.4835 GHz

• Channel Bandwidth : Supports 20 MHz

• Security : 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

• Transmission Rate : 11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps

• Wi-Fi Pairing : AP Pairing

• Protocol : EZVIZ Cloud Proprietary Protocol

• Interface Protocol : EZVIZ Cloud Proprietary Protocol

• Wired Network : RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Function :

• Detection :

  • Motion Detection

  • AI-Powered Human Shape Detection

  • Waving-Hand Detection

• Customized Alert Area : Supports

• Integration : Works with Alexa, Google Assistant

• General Function :

  • Anti-Flicker

  • Dual-Stream

  • Heart Beat

  • Mirror Image

  • Password Protection

  • Watermark

Storage :

• Local Storage : Supports microSD card (Up to 512 GB)

• Cloud Storage : Supports EZVIZ CloudPlay storage

  • (Subscription required)

General :

• Operating Conditions :

  • -22°F to 122 °F (-30ºC ~ 50ºC );

  • Humidity 95% or less ( non-condensing)

• IP Grade : IP67

• Power Supply : DC 12V / 1A

• Power Consumption : MAX. 9W

• Dimensions :

  • 72 × 84 × 152 mm (2.83 × 3.31 × 5.98 inch)

• Packaging Dimensions :

  • 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch)

• Weight(With Package) : 539 g (19.01 oz)

• Net Weight : 330 g (11.64 oz)

In the Box :

• H3c 3K Camera

• Drill Template

• Screw Kit

• Waterproof Kit

• Power Adapter

• Regulatory Information

• Quick Start Guide

Certifications : CE / UL / WEEE / RoHS / REACH
