HILOOK Analog Camera Turret Indoor 5MP (3K) THC-T150-P, Indoor Fixed Turret Camera

HILOOK Analog Camera Turret Indoor 5MP (3K) THC-T150-P, Indoor Fixed Turret Camera

Overview :

• High quality imaging with 5 MP, 2560 × 1944 resolution

• 2.8 mm and 3.6 mm fixed focal lens

• Up to 20 m IR distance for bright night imaging

• One port for four switchable signals (TVI/AHD/CVI/CVBS)

Camera :

• Image Sensor : 5 MP CMOS

• Max. Resolution : 2560 (H) × 1944 (V)

• Min. Illumination :

  • Color : 0.01 Lux @ (F2.0, AGC ON)

  • 0 Lux with IR

• Shutter Time :

  • PAL : 1/25 s to 1/50, 000 s

  • NTSC : 1/30 s to 1/50, 000 s

• Day & Night : ICR

• Angle Adjustment :

  • Pan : 0° to 360°

  • Tilt : 0° to 75°

  • Rotate : 0° to 360°

• Signal System : PAL/NTSC

Lens :

• Lens Type : 2.8 mm and 3.6 mm fixed focal lens

• Focal Length & FOV :

  • 2.8 mm :

    • Horizontal : 85°, Vertical : 63°, Diagonal : 110°

  • 3.6 mm :

    • Horizontal : 80°, Vertical : 63°, Diagonal : 105°

• Lens Mount : M12

Image :

• Image Parameters Switch : STD/HIGH-SAT

• Image Settings :

  • Brightness

  • Sharpness

  • Mirror

  • Smart IR

  • AGC

• Frame Rate :

  • TVI :

    • 5 M @ 20 fps

    • 4 M @ 30 fps

    • 4 M @ 25 fps

    • 1080p @ 30 fps

    • 1080p @ 25 fps

  • AHD :

    • 5 M @ 20 fps

    • 4 M @ 30 fps

    • 4 M @ 25 fps

  • CVI :

    • 4 M @ 30 fps

    • 4 M @ 25 fps

  • CVBS : PAL/NTSC

• Day/Night Mode : Auto/Color/BW (Black and White)

• Wide Dynamic Range (WDR) : Digital WDR

• Image Enhancement : BLC, HLC

• White Balance : ATW/MANUAL

Interface :

• Video Output : 1 HD analog output

General :

• Material : Plastic

• Dimension : Ø 85.4 mm × 76.12 mm (Ø 3.38" × 2.67")

• Approx. 120 g (0.26 lb.)

• Operating Condition :

  • -40 °C to 60 °C (-40 °F to 140 °F)

  • Humidity: 90% or less (non-condensation)

• Communication : HIKVISION-C

• Language : English

• Power Supply : 12 VDC ±25%

• Consumption : Max. 4.3 W

• IR Range : Up to 20 m
