HILOOK Analog Camera Turret Indoor 2MP (1080P) THC-T120-PC, Indoor Fixed Turret Camera

HILOOK Analog Camera Turret Indoor 2MP (1080P) THC-T120-PC, Indoor Fixed Turret Camera

Overview :

• 1080p turret camera

• Smart IR, up to 20 m IR distance

• 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)

Interface :

• Video Output : 1 HD analog output

• Switch Button : TVI/AHD/CVI/CVBS

• Menu : Day/Night Mode

• IR cut filter : DWDR (Digital Wide Dynamic Range)

Support :

• Language : English

• Functions : Brightness, Sharpness, DNR, Mirror, Smart IR

• Backlight Compensation : Support

Camera :

• Image Sensor : 2 MP CMOS image sensor

• Signal System : PAL/NTSC

• Frame Rate :

  • PAL : 1080p@25fps

  • NTSC : 1080p@30fps

• Resolution : 1920 (H) × 1080 (V)

• Shutter Time ; 1/25 (1/30) s to 1/50,000 s

• Min. illumination : 0.02 Lux@(F2.0, AGC ON), 0 Lux with IR

• Lens : 2.8 mm, 3.6 mm

• Horizontal Field of View :

  • 2.8 mm :

    • Horizontal : 96.5°, Vertical : 48.9°, Diagonal : 120.5°

  • 3.6 mm :

    • Horizontal : 76.9°, Vertical : 40.6°, Diagonal : 92.0°

• Lens Mount : M12

• Day & Night : IR cut filter

• Synchronization : Internal synchronization

• Angle Adjustment :

  • Pan : 0° to 360°

  • Tilt : 0° to 75°

  • Rotation : 0° to 360°

General :

• Power Supply : 12 VDC ± 15%

• Power Consumption : Max. 2.1 W

• Material : Plastic

• IR Range : Up to 20 m

• Dimensions : Ø 85.4 mm × 76.12 mm ( Ø 3.38" × 2.67")

• 130 g (0.29 lb.)

• Operating Conditions :

  • -40 °C to 60 °C (-40 °F to 140 °F),

  • Humidity :  90% or less (non-condensation)
