HIKVISION DS-2CE16K0T-LPFS, 5MP (3K) Smart Hybrid Light Audio Fixed Mini Bullet Camera

HIKVISION DS-2CE16K0T-LPFS, 5MP (3K) Smart Hybrid Light Audio Fixed Mini Bullet Camera

Overview :

• High quality imaging with 3K, 2960 × 1665 resolution

• 2.8 mm and 3.6 mm fixed focal lens

• Up to 25 m IR distance for bright night imaging

• Up to 20 m white light distance for bright night imaging

• One port for four switchable signals (TVI/AHD/CVI/CVBS）

• Water and dust resistant (IP67)

• High quality audio with audio over coaxial cable, built-in mic

• Smart-Hybrid light, optimize your security with flexible lighting options

Spesifikasi :

Camera :

• Image Sensor : 3K CMOS

• Max. Resolution : 2960 (H) × 1665 (V)

• Min. Illumination :

  • 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR

• Shutter Time :

  • PAL : 1/25 s to 1/50, 000 s

  • NTSC : 1/30 s to 1/50, 000 s

• Day & Night : ICR

• Angle Adjustment :

  • Pan : 0 to 360°

  • Tilt : 0 to 90°

  • Rotation : 0 to 360°

• Signal System : PAL/NTSC

Lens :

• Lens Type : 2.8 mm and 3.6 mm fixed focal lens

• Focal Length & FOV :

  • 2.8 mm,

    • Horizontal : 105°, Vertical : 62°, Diagonal : 132°

  • 3.6 mm

    • Horizontal : 92°, Vertical : 48°, Diagonal : 112°

• Lens Mount : M12

Microphone

• Pickup Distance : In a radius of 5 m

• Amount : 1

Illuminator :

• Supplement Light Range :

• • IR : Up to 25 m

• • White Light : Up to 20 m

• Supplement Light Type : Smart, IR, White Light

Image :

• Image Settings : Brightness, Sharpness, Smart IR

• Frame Rate :

  • TVI :

    • 3K@20 fps

    • 4 MP@25 fps/30 fps

    • 1080p@25 fps/30 fps

  • AHD : 4 MP@25 fps/30 fps

  • CVI : 4 MP@25 fps/30 fps

  • CVBS : PAL/NTSC

• Day/Night Mode :Auto/Color

• Wide Dynamic Range (WDR) : Digital WDR

• Image Enhancement : DWDR/BLC/HLC/Global

• White Balance : Auto/Manual

• AGC : Yes

Interface :

• Video Output : Switchable TVI/AHD/CVI/CVBS

General :

• Material : Plastic

• Dimension : 138.8 mm × Ø70 mm (5.47" × Ø2.76")

• Approx. 160 g (0.35 lb.)

• Operating Condition :

  • -40 °C to 60 °C (-40 °F to 140 °F)

  • Humidity: 90% or less (non-condensation)

• Communication : HIKVISION-C

• Language : English

• Power Supply : 12 VDC ± 25%

  • *You are recommended to use one power adapter to
            supply the power for one camera.

• Consumption : Max. 2.9 W

• Protection : IP67
