DAHUA Desktop Switch CS4010-8GT-60, 10-Port Cloud Managed Desktop Gigabit Switch with 8-Port PoE

DAHUA Desktop Switch CS4010-8GT-60, 10-Port Cloud Managed Desktop Gigabit Switch with 8-Port PoE

Basic :

• Layer : Layer 2

• Switching Capacity : 20 Gbps

• Packet Forwarding Rate : 14.88 Mpps

• Description of Function Slots :

• Port 1-8 : 8 × RJ-45 10/100/1000 Mbps (PoE)

• Port 9-10 : 2 × RJ-45 10/100/1000 Mbps (uplink)

• Operating Temperature : –10 °C to +55 °C (+14 °F to +131 °F)

• Operating Humidity : 10%–90% (RH), non-condensing

• Storage Temperature : –40 °C to +75 °C (–40 °F to +167 °F)

• Storage Humidity : 5%–95% (RH), non-condensing

• Power Supply : External Power Adapter (53 V, 1.22 A)

• Power Consumption :

  • Idling : 4 W

  • Full load : 63 W

• Statics Protection :

  • Air discharge : 8 kV

  • Contact discharge : 6 kV

• Lightning Protection :

  • Common mode : 6 kV

  • Differential mode : 1 kV

• Net Weight : 0.36 kg (0.79 lb)

• Gross Weight : 0.95 kg (2.09 lb)

• Product Dimensions (L × W × H) :

  • 184.6 mm × 103.3 mm × 27 mm (7.27" × 4.07" × 1.06")

• Packaging Dimensions (L × W × H) :

  • 252 mm × 137 mm × 113 mm (9.92" × 5.39" × 4.45")

• Casing Material : Sheet metal

• Installation : Desktop mount; wall mount

 PoE :

• PoE : Yes

•  PoE Power : Port 2-8≤30 W, port 1≤60 W, total≤60 W

• PoE Protocol : IEEE 802.3af; IEEE 802.3at; Hi-PoE

• PoE Power Consumption Management :

  • PoE power consumption management

  • PoE power on/off

  • Turns off PoE if overload is detected

• PoE Pin Assignment : 1,2, (V+), 3 ,6, (V-)

• Long Distance PoE Transmission : Yes

Hardware :

• DIP Switch :

  • Managed Mode :

    • On by default for both local web and cloud management.

    • Off for Unmanaged Mode.

  • PoE Watchdog :

    • Monitors ports 1-8 and auto-restarts the PoE port when
            there is no traffic for 2 min.
            (Only works when Managed Mode is Off)

  • Extend Mode :

    • Ports 1-8; transmission distance up to 250 meters at 10 Mbps.

      • (Only works when Managed Mode is Off)

• Reset Button : 1

Performance :

• MTBF : 2,482,955 hours

• Packet Buffer Size : 4 Mbit

• Jumbo Frame : 15360 Byte

• MAC Table Size : 8K

• Communication Standard :

  • IEEE 802.3

  • IEEE 802.3u

  • IEEE 802.3x

  • IEEE 802.3ab

  • IEEE 802.3az

  • IEEE 802.3ad

• VLAN Number : 32

Feature :

• Ethernet Loop Protection : STP; RSTP

• VLAN Function : IEEE 802.1Q VLAN

• Link Aggregation : Static Aggregation

• Port Feature :

  • IEEE 802.3x Flow Control

  • Unknown Unicast Suppression

  • Multicast Storm Control

  • Broadcast Storm Control

  • MAC+Port Binding

  • Loop Prevention

•  Mirror :

  • Local Port Mirroring

  • N : 1 Mirroring

• Reliability : LLDP

• DHCP Function : DHCP Client

• Security : Port Isolation

• Equipment Management :

  • Web Management

  • Cloud Management

  • Logs

  • Fault Alarm

General

In the Box :

• 1 × User Manual

• 1 × Legal and Regulatory Information

• 1 × Power Cord

• 1 × Power Adapter

Certifications : CE
