DAHUA Analog Camera Turret Indoor 2MP (1080P) HAC-T1A29P, Full-Color Starlight
Kamera pengawas full color resolusi tinggi
Rp1.00
DAHUA Analog Camera Turret Indoor 2MP (1080P) HAC-T1A29P, Full-Color Starlight
Full-color starlight :
20 m illumination distance
Max. 30fps@1080P
CVI/CVBS/AHD/TVI switchable
Fixed lens (2.8 mm)
IP67, 12V±30% DC
Camera :
Pixel : 2 MP
Image Sensor : 2MP CMOS
Max. Resolution : 1920 (H) × 1080 (V)
Scanning System : Progressive
Electronic Shutter Speed :
PAL : 1/25 s–1/100,000 s
NTSC : 1/30 s–1/100,000 s
Min. Illumination :
0.04 lux@F2.0 (Color, 30 IRE)
0.004 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio : >65 dB
Illumination Distance : 20 m (65.62 ft)
Illuminator On/Off Control : Auto/Manual
Illuminator Number : 1 (IR light)
Pan/Tilt/Rotation Range :
Pan : 0°–360°
Tilt : 0°–78°
Rotation : 0°–360°
Lens :
Lens Type : Fixed-focal
Lens Mount : M12
Focal Length : 2.8 mm; 3.6 mm; 6 mm
Max. Aperture : F2.0
Field of View :
2.8 mm: H : 100°; V : 53°; D : 120°
3.6 mm: H : 82°; V : 42°; D : 98°
6 mm: H : 53°; V : 30°; D : 60°
Iris Control : Fixed
Close Focus Distance
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.0 m (3.28 ft)
6 mm: 2.0 m (6.56 ft)
Port :
Video Output
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power :
Power Supply : 12 VDC ± 30%
Power Consumption : Max. 2.3 W (12 VDC, IR on)
Environment :
Operating Temperature : –40 °C to +60 °C (–40 °F to 140 °F)
Operating Humidity : <95% (RH), non-condensing
Storage Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
Structure :
Casing : Plastic
Product Dimensions :
Φ85.4 mm × 68.8 mm (Φ3.36" × 2.71")
Packaging Dimensions :
109 mm × 109 mm × 85 mm (4.29" × 4.29" × 3.35")
Net Weight : 0.09 kg (0.20 lb)
Gross Weight : 0.13 kg (0.29 lb)
Installation : Wall mount; ceiling mount; horizontal pole mount
Certifications :
CE :
EN55032:2015
EN61000-3-2:2014
EN61000-3-3:2013
EN55024:2010+A1:2015
EN55035:2017
EN50130-4:2011+A1:2014
EN62368-1:2014+A11:2017
FCC :
CFR 47 FCC Part 15 subpartB
ANSI C63.4-2014
UL :
UL62368-1+CAN/CSA C22.2 No.62368-1
