DAHUA Analog Camera Turret Indoor 2MP (1080P) HAC-T1A21-U, IR HDCVI Fixed-focal Eyeball Camera

DAHUA Analog Camera Turret Indoor 2MP (1080P) HAC-T1A21-U, IR HDCVI Fixed-focal Eyeball Camera

Overview :

• 2MP IR HDCVI Fixed-focal Eyeball Camera

• Max. 30 fps@1080p

• Smart IR Illumination

• 25 m illumination distance.

• Quick-to-install eyeball saves installation time.

• 3.6 mm fixed lens (2.8 mm optional).

• CVI/CVBS/AHD/TVI switchable.

SPESIFIKASI :

Camera :

• Image Sensor : 2 MP CMOS

• Max. Resolution : 1920 (H) × 1080 (V)

• Scanning System : Progressive

• Electronic Shutter Speed :

  • PAL: 1/25 s–1/100,000 s

  • NTSC: 1/30 s–1/100,000 s

• Min. Illumination :

  • 0.02 lux@F2.0 (Color, 30 IRE)

  • 0.002 lux@F2.0 (B/W, 30 IRE)

  • 0 lux (Illuminator on)

• S/N Ratio : >65 dB

• Illumination Distance : 25 m (82.02 ft)

• Illuminator On/Off Control : Auto/Manual

• Illuminator Number : 1 (IR light)

• Angle Adjustment : Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°

Lens :

• Lens Type : Fixed-focal

• Lens Mount : M12

• Focal Length : 2.8 mm; 3.6 mm

• Max. Aperture : F2.0

• Field of View :

  • 2.8 mm: H: 100°; V: 54°; D: 117°

  • 3.6 mm: H: 80°; V: 43°; D: 94°

• Iris Control : Fixed

• Close Focus Distance :

  • 2.8 mm: 0.5 m (1.64 ft)

  • 3.6 mm: 0.8 m (2.62 ft)

• Video Frame Rate :

  • PAL: 1080p@25 fps

  • NTSC: 1080p@30 fps

• Resolution :

  • 1080p (1920 × 1080)

  • 960H (960 × 576/960 × 480)

• Day/Night : Auto(ICR)/Color/B/W

• BLC : BLC; DWDR

• WDR : DWDR

• White Balance : Auto

• Gain Control : Auto

• Noise Reduction : 2D NR

• Illumination Mode : Smart IR

Port :

• Video Output :

  • Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power :

• Power Supply : 12 VDC ± 30%

• Power Consumption : Max 2.3 W (12 VDC, IR on)

Environment :

• Operating Temperature : –40 °C to +60 °C (–40 °F to +140 °F)

• Operating Humidity : <95% (RH), non-condensing

• Storage Temperature : –40 °C to +60 °C (–40 °F to +140 °F)

• Storage Humidity : <95% (RH), non-condensing

• Anti-corrosion Level : Basic Protection

Structure :

• Casing Material : Plastic

• Product Dimensions : Φ85.0 mm × 77.1 mm (Φ3.35" × 3.04")

• Net Weight : 0.11 kg (0.24 lb)

• Gross Weight : 0.12 kg (0.26 lb)

• Installation : Wall mount; ceiling mount

Certifications :

• CE-LVD: EN 62368-1

• CE-EMC: EN 55032; EN 55035
